Parameters:

²  Dimension:   23*12.2*27.7mm

²  Weight:  14 ± 1 g

²  Torque:  1.2 kg-cm (4.8V), 1.5 kg-cm (6.0V)

²  Speed:  0.11 sec/60 degree (4.8V), 0.08 sec/60 degree (6.0V)

²  Operating Voltage:  4.8V-6V

²  Rotation Angle:  165 degree (when 800-2200 μ sec)

²  Horn gear spline:  20T*Φ4.82mm

²  Gear Materials:  copper & plastic

²  Motor Type: coreless motor

²  Bearing: none

²  Case Material:  ABS

²  Splash Water Resistance: no

²  Dead Band:   4~5μs

Applications:

Suitable for RC airplane
